Rider Pallets Trucks Eyt20-30Rt(S)
Product Details:
- Length 2325 Millimeter (mm)
- Height 82.5 Millimeter (mm)
- Product Type Pallets Trucks
- Body Material Metal
- Type Rider
- Click to View more
Rider Pallets Trucks Eyt20-30Rt(S) Price And Quantity
- 11500 INR/Unit
- 1 Unit
Rider Pallets Trucks Eyt20-30Rt(S) Product Specifications
- Rider
- Pallets Trucks
- Metal
- 2325 Millimeter (mm)
- 82.5 Millimeter (mm)
Rider Pallets Trucks Eyt20-30Rt(S) Trade Information
- Telegraphic Transfer (T/T)
- 1 Unit Per Day
- 1 Days
- All India
Product Description
Rider Pallets Trucks Eyt20-30Rt(S)
Specifications of the product
| Characteristics | ||||
| 1.1 | Manufacturer |
| National Hydraulics | |
| 1.2 | Model designation |
| EYT20-30RT（S） | EYT20-35RT（S） |
| 1.3 | Model designation |
| Battery | Battery |
| 1.4 | Drive unit |
| Ride | Ride |
| 1.5 | Load capacity | Q (kg) | 3000 | 3500 |
| 1.6 | Load center | c (mm) | 600 | 600 |
| Weights | ||||
| 2.1 | Service weight (Incl. battery) | kg | 570 | 690 |
| Wheels, Chassis | ||||
| 3.1 | Tyre type，operator side/ load side |
| PU/PU | PU/PU |
| 3.5 | Wheels, number operator/load side (x=drive wheels) |
| 1/2/2 | 1/2/2 |
| Dimensions | ||||
| 4.4 | Lift height | h3 (mm) | 140 | 140 |
| 4.15 | Fork height, lowered | h13 (mm) | 82.5 | 82.5 |
| 4.19 | Overall length | l1 (mm) | 2325 | 2325 |
| 4.21 | Overall width | b1/ b2 (mm) | 915 | 915 |
| 4.22 | Fork dimensions | s/ e/ l (mm) | 60/230/1190 | 60/230/1190 |
| 4.25 | Fork spread, min/ max | b5 (mm) | 685 | 710 |
| 4.33 | Aisle width, 1000×1200 pallet crossways | Ast (mm) | 2555 | 3765 |
| 4.35 | Outer turning radius | Wa (mm) | 2064 | 2590 |
| Performance | ||||
| 5.1 | Travel speed, laden/ unladen | km/ h | 10.5/14.5 | 10.5/14.5 |
| 5.2 | Lifting speed, laden/ unladen | m/ s | 30/33 | 30/33 |
| 5.3 | Lowering speed, laden/ unladen | m/ s | 40/38 | 40/38 |
| 5.8 | Maximum gradeability, laden/ unladen S2 5 min. | % | 6/15 | 6/15 |
| 5.10 | Service brake |
| Electromagnetic | Electromagnetic |
| Drive | ||||
| 6.1 | Drive motor rating S2 60 min. | kW | 4 | 4 |
| 6.2 | Lift motor rating at S3 15% | kW | 2.2 | 2.2 |
| 6.4 | Battery voltage/ rated capacity (5h) | V/ Ah | 24/360 | 24/360 |
| Others | ||||
| 8.1 | Type of drive control |
| AC ZAPI | |
| 8.4 | Sound level at operator's ear | dB (A) | 70 | |
