U-Series Low-Profile Lift Table
11500 INR/Unit
Product Details:
- Weight 280-380 Kilograms (kg)
- Product Type U-Series Low-Profile Lift Table
- Condition New
- Lifting Capacity 1000-1500 Kilograms (kg)
- Feature "U" Shaped Top Platform
- Attributes Durable
- Click to View more
X
U-Series Low-Profile Lift Table Price And Quantity
- 1 Unit
- 11500 INR/Unit
U-Series Low-Profile Lift Table Product Specifications
- Durable
- New
- U-Series Low-Profile Lift Table
- 1000-1500 Kilograms (kg)
- 280-380 Kilograms (kg)
- "U" Shaped Top Platform
U-Series Low-Profile Lift Table Trade Information
- Telegraphic Transfer (T/T)
- 1 Unit Per Day
- 1 Days
- All India
Product Description
U-Series Low-Profile Lift Table
Features
- "U" Shaped Top Platform
- "U" shaped tables are specially for handling pallets, no need for a pit or load ramps.
- They are manufactured to all European safety standards including EN1570:1999.
- Remote Power pack with pedestal and controls,pretected to IP54.
- Upper platform fitted with safety perimeter to prevent descent on contact with obstructions.
- 24V control box with UP and DOWN buttons and emergency stop.
- External power pack equipped with a relief valve against overloading and a compensated flow valve for controlling lowering speed.
- Hose burst safety valve to stop the lift table lowering a case of hose breakage.
Specifications of the product
| Model | UNIT | HU1000 | HU1500 |
| Capacity | (kg) | 1000 | 1500 |
| Max.Height | H(mm) | 860 | 860 |
| Collapsed Height | h(mm) | 85 | 105 |
| Platform | BxC(mm) | 1450x1140 | 1600x1180 |
| Lifting time | (seconds) | 25 | 30 |
| Power Pack |
| 380V/50HZ,AC 1.1KW | 380V/50HZ,AC 1.5KW |
| Net Weight | (kg) | 280 | 380 |
